• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Thread Size	1/2-13
Overall Height (in)	3.93 in
Base Width (in)	1.88 in
Overall Length (in)	4.63 in
Overall Width (in)	2 in
Bore Diameter (in)	1.5000 in
Thread Depth (in)	0.75 in
Base to Center Height (in)	1.9375 in
Length Through Bore (in)	2.000 in
Centerline to Outermost Bearing Face (in)	1.25 in
Bolt Spacing (in)	3.500 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Tapped Base
Seal Type	Felt Labyrinth Seal
Housing Style	Pillow Block
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	2.688 in
Inner Race Heat Treat Method	Zone-Hardened
Bearing Insert Finish	Black Oxide
Lubricant	Lithium Complex NLGI 2 Grease
Cage Type	Land Riding Retainer
Bearing Insert Material	52100 Bearing Steel
Base Length (in)	4.625 in
Max Operating Temperature (F)	220 °F
Bearing Type	Standard Duty
Radial Clearance	Standard
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Dynamic Load Rating (lb)	7,340 lb
Housing Material	Cast Iron
Shaft Locking Type	Concentric
Grease Fitting Thread Size	1/4-28
Maximum Speed (RPM)	5850 rpm
Insert	2-18T
Housing Coating	Powder Coated
Inner Ring Outside Diameter (in)	2.0625 in
Size Code	2-19
Static Load Rating (lb)	4,467 lb
End Cap Available	No
Housing Width (in)	1.88 in

General Specifications

UPC	662461031070
Weight	5.33 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8483.20.8040
Country of Origin	United States of America
