• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Thread Size	1/2-13
Overall Height (in)	3.93 in
Overall Length (in)	4.63 in
Base Width (in)	1.88 in
Overall Width (in)	1.94 in
Bore Diameter (in)	1.5000 in
Thread Depth (in)	0.75 in
Base to Center Height (in)	1.9375 in
Length Through Bore (in)	1.9375 in
Centerline to Outermost Bearing Face (in)	1.1875 in
Bolt Spacing (in)	3.500 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Housing Construction	One Piece
Bore Shape	Straight
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Pillow Block, Tapped Base
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Cage Type	Land Riding Retainer
Radial Clearance	Standard
Housing Material	Cast Iron
Bearing Type	Standard Duty
Bearing Insert Material	52100 Bearing Steel
Size Code	2-19
Static Load Rating (lb)	4,467 lb
End Cap Available	No
Grease Fitting Thread Size	1/4-28
Shaft Locking Type	Set Screw
Dynamic Load Rating (lb)	7,340 lb
Bearing Insert Finish	Black Oxide
Base Length (in)	4.625 in
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Coating	Powder Coated
Inner Ring Outside Diameter (in)	2.0625 in
Maximum Speed (RPM)	4150 rpm
Insert	2-18
Max Operating Temperature (F)	220 °F
Lubricant	Lithium Complex NLGI 2 Grease
Fixed vs. Expansion	Fixed
Housing Width (in)	1.88 in

General Specifications

UPC	662461007259
Weight	5.00 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8483.20.8040
Country of Origin	United States of America
