• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal with black oxide bearing races
• Metric fitting and mounting bolts
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Thread Size	1/2-13
Overall Height (in)	4.25 in
Base Width (in)	2 in
Overall Length (in)	5 in
Overall Width (in)	2 in
Bore Diameter (mm)	45 mm
Base to Center Height (in)	2.125 in
Thread Depth (in)	0.75 in
Length Through Bore (in)	2.000 in
Bolt Spacing (in)	3.750 in
Centerline to Outermost Bearing Face (in)	1.188 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Housing Construction	One Piece
Bore Shape	Straight
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Tapped Base
Seal Type	Single Lip Contact Seal
Housing Style	Pillow Block
Locking Collar Outside Diameter (in)	2.938 in
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Bearing Insert Material	52100 Bearing Steel
Housing Material	Cast Iron
Radial Clearance	Standard
End Cap Available	No
Insert	5209TMC
Lubricant	Lithium Complex NLGI 2 Grease
Shaft Locking Type	Concentric
Misalignment Capability	±2.0° Misalignment - Static Only
Fixed vs. Expansion	Fixed
Inner Ring Outside Diameter (in)	2.297 in
Dynamic Load Rating (lb)	7,901 lb
Maximum Speed (RPM)	3800 rpm
Housing Coating	Powder Coated
Static Load Rating (lb)	5,139 lb
Cage Type	Land Riding Retainer
Grease Fitting Thread Size	M8 x 1MM
Bearing Type	Standard Duty
Size Code	2-111
Base Length (in)	5.000 in
Bearing Insert Finish	Black Oxide
Max Operating Temperature (F)	220 °F
Housing Width (in)	2 in

General Specifications

UPC	662461254110
Weight	6.80 LB
Packaged Length	6.06 IN
Packaged Width	5.94 IN
Packaged Height	2.19 IN
HTC	8483.20.8040
Country of Origin	United States of America
