• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal with black oxide bearing races
• Metric fitting and mounting bolts
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Thread Size	1/2-13
Overall Length (in)	4.41 in
Overall Height (in)	3.75 in
Base Width (in)	1.75 in
Overall Width (in)	1.88 in
Bore Diameter (mm)	35 mm
Base to Center Height (in)	1.874 in
Thread Depth (in)	0.75 in
Length Through Bore (in)	1.6875 in
Bolt Spacing (in)	3.25 in
Centerline to Outermost Bearing Face (in)	1.12 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Pillow Block, Tapped Base
Housing Style	Pillow Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Housing Coating	Powder Coated
Radial Clearance	Standard
Bearing Insert Material	52100 Bearing Steel
Dynamic Load Rating (lb)	5,782 lb
Inner Ring Outside Diameter (in)	1.8620 in
Maximum Speed (RPM)	4650 rpm
Bearing Type	Standard Duty
Max Operating Temperature (F)	220 °F
Size Code	2-17
Grease Fitting Thread Size	M8 x 1MM
Lubricant	Lithium Complex NLGI 2 Grease
Misalignment Capability	±2.0° Misalignment - Static Only
End Cap Available	No
Static Load Rating (lb)	3,493 lb
Fixed vs. Expansion	Fixed
Shaft Locking Type	Concentric
Base Length (in)	4.25 in
Insert	5207TMC
Bearing Insert Finish	Black Oxide
Housing Material	Cast Iron
Cage Type	Land Riding Retainer
Housing Width (in)	1.88 in

General Specifications

UPC	662461254097
Weight	4.80 LB
Packaged Length	2.00 IN
Packaged Width	5.00 IN
Packaged Height	5.00 IN
HTC	8483.20.8040
Country of Origin	United States of America
