• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Height (in)	4.00 in
Overall Length (in)	4.44 in
Overall Width (in)	1.75 in
Bore Diameter (in)	1.1875 in
Base to Center Height (in)	2.75 in
Length Through Bore (in)	1.50 in
Slot Width (in)	0.531 in
Slot Spacing (in)	3.500 in
Centerline to Outermost Bearing Face (in)	0.875 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Series	ST
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Take-Up Block, Wide Slot
Seal Type	Single Lip Contact Seal
Slot Length (in)	2.25 in
Housing Style	Take-Up Block
Inner Race Heat Treat Method	Zone-Hardened
Adjusting Screw Square Nut Seat Height (in)	1.44 in
Ability to Relubricate	Yes
Setscrew Torque (in-lbs)	65-85 in/lbs
Adjusting Screw Clearance Hole Diameter (in)	0.88 in
Carriage Bolt Size (in)	5/8 in
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Outer Ring Defect	0.0595 cps
Housing Coating	Powder Coated
Vibration Frequency Roller Spin	0.0385 cps
Radial Clearance	Standard
Bearing Type	Standard Duty
Shaft Locking Type	Set Screw
Housing Material	Cast Iron
End Cap Available	No
Vibration Frequency Fundamental Train	0.0066 cps
Static Load Rating (lb)	2,567 lb
Maximum Speed (RPM)	5450 rpm
Insert	2-13C
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Inner Ring Defect	0.0905 cps
Lubricant	Lithium Complex NLGI 2 Grease
Fixed vs. Expansion	Fixed
Max Operating Temperature (F)	220 °F
Size Code	2-13
Grease Fitting Thread Size	1/4-28
Dynamic Load Rating (lb)	4,381 lb
Bearing Insert Finish	Black Oxide
Cage Type	Land Riding Retainer
Inner Ring Outside Diameter (in)	1.594 in

General Specifications

UPC	662461023990
Weight	3.11 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.4040
Country of Origin	United States of America
