• 440C Stainless steel for corrosion resistance.
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	1.94 in
Length Through Bore (in)	1.938 in
Bore Diameter (in)	1.5 in
Centerline to Outermost Bearing Face (in)	1.188 in

Technical Specifications

Series	SS
Rolling Element	Ball Bearing
Housing Type	Insert Only
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Options	Corrosion Resistant
Bore Shape	Straight
Seal Type	Triple Lip Contact Seal
Certifications	IP69K
Outside Diameter (in)	3.15
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Through Hardened with annealed set screw hole
Maximum Speed (RPM)	1750 rpm
Radial Clearance	Standard
Static Load Rating (lb)	4,467 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Max Operating Temperature (F)	220 °F
Dynamic Load Rating (lb)	6,239 lb
End Cap Available	No
Fixed vs. Expansion	No
Cage Type	Land Riding Retainer
Shaft Locking Type	Set Screw
Lubricant	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Inner Ring Outside Diameter (in)	2.063 in
Bearing Insert Material	440C Stainless Steel

General Specifications

UPC	662461422076
Weight	1.90 LB
Packaged Length	3.63 IN
Packaged Width	2.00 IN
Packaged Height	3.63 IN
HTC	8482.10.5052
Country of Origin	China
