• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	1.38 in
Overall Length (in)	4.75 in
Overall Height (in)	2.81 in
Base Width (in)	1.31 in
Bolt Size (in)	3/8 in
Bore Diameter (in)	1 in
Base to Center Height (in)	1.5000 in
Foot Height (in)	0.17 in
Length Through Bore (in)	1.375 in
Bolt Spacing Max (in)	4.38 in
Centerline to Outermost Bearing Face (in)	0.875 in
Bolt Spacing Min (in)	2.88 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Pilot Configuration	No Pilot
Housing Color	Black Oxided
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	No
Bearing Insert Finish	Black Oxide
Inner Ring Outside Diameter (in)	1.375 in
Vibration Frequency Roller Spin	0.0442 cps
Dynamic Load Rating (lb)	2,801 lb
Bearing Insert Material	52100 Bearing Steel
Grease Fitting Thread Size	1/4-28
Vibration Frequency Inner Ring Defect	0.0985 cps
Bearing Type	Standard Duty
Misalignment Capability	Limited - Static Only
Vibration Frequency Outer Ring Defect	0.0682 cps
Fixed vs. Expansion	Fixed
Size Code	2-015
Max Operating Temperature (F)	220 °F
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Fundamental Train	0.0068 cps
Cage Type	Land Riding Retainer
Base Length (in)	4.75 in
Static Load Rating (lb)	1,651 lb
Housing Material	Stamped Steel
End Cap Available	No
Shaft Locking Type	Set Screw
Radial Clearance	Standard
Insert	SRC-16
Maximum Speed (RPM)	6350 rpm

General Specifications

UPC	662461005606
Weight	0.94 LB
Packaged Length	3.19 IN
Packaged Width	1.69 IN
Packaged Height	5.25 IN
HTC	8483.20.8040
Country of Origin	United States of America
