• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	3/8 in
Overall Width (in)	2.7 in
Overall Length (in)	4.5 in
Overall Height (in)	1.375 in
Bore Diameter (in)	1 in
Foot Height (in)	0.06 in
Length Through Bore (in)	1.375 in
Bolt Spacing (in)	3.6250 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Silver
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Ability to Relubricate	No
Setscrew Torque (in-lbs)	85 in/lbs
Inner Race Heat Treat Method	Zone-Hardened
Housing Material	Stamped Steel
Bearing Insert Finish	Black Oxide
Misalignment Capability	Limited - Static Only
Size Code	2-015
Vibration Frequency Outer Ring Defect	0.0682 cps
Static Load Rating (lb)	1,651 lb
Maximum Speed (RPM)	6350 rpm
Shaft Locking Type	Set Screw
Bearing Type	Standard Duty
Max Operating Temperature (F)	220 °F
Vibration Frequency Inner Ring Defect	0.0985 cps
Radial Clearance	Standard
Inner Ring Outside Diameter (in)	1.375 in
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Fundamental Train	0.0068 cps
End Cap Available	No
Fixed vs. Expansion	Fixed
Vibration Frequency Roller Spin	0.0442 cps
Cage Type	Land Riding Retainer
Lubricant	Lithium Complex NLGI 2 Grease
Insert	SRC-16
Dynamic Load Rating (lb)	2,801 lb

General Specifications

UPC	662461005507
Weight	0.85 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	United States of America
