• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	2.7 in
Bolt Size (in)	3/8 in
Overall Length (in)	4.5 in
Overall Height (in)	1.375 in
Bore Diameter (in)	0.75 in
Foot Height (in)	0.06 in
Length Through Bore (in)	1.278 in
Bolt Spacing (in)	3.6250 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Housing Color	Silver
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Ability to Relubricate	No
Inner Race Heat Treat Method	Zone-Hardened
Static Load Rating (lb)	1,444 lb
Insert	SRC-12
Vibration Frequency Roller Spin	0.0381 cps
Inner Ring Outside Diameter (in)	1.192 in
Bearing Insert Finish	Black Oxide
Lubricant	Lithium Complex NLGI 2 Grease
End Cap Available	No
Size Code	2-012
Bearing Type	Standard Duty
Dynamic Load Rating (lb)	2,611 lb
Cage Type	Land Riding Retainer
Bearing Insert Material	52100 Bearing Steel
Max Operating Temperature (F)	220 °F
Vibration Frequency Inner Ring Defect	0.0907 cps
Maximum Speed (RPM)	7300 rpm
Shaft Locking Type	Set Screw
Radial Clearance	Standard
Housing Material	Stamped Steel
Vibration Frequency Outer Ring Defect	0.0593 cps
Vibration Frequency Fundamental Train	0.0066 cps
Misalignment Capability	Limited - Static Only
Fixed vs. Expansion	Fixed

General Specifications

UPC	662461005477
Weight	0.80 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	United States of America
