• Cast iron housed, extended inner ring bearing with ball riding nylon retainer
• Designed to accommodate optional closed or open end to allow users to better conform OSHA requirements for personal protection
• Skwezloc® Concentric locking for near perfect concentricity
• Single lip contact seal and flinger
• Supplied sealed for life with optional lubrication fitting in the box

Dimensions

Overall Width (in)	4.38 in
Bolt Size (in)	9/16 in
Overall Height (in)	2.109 in
Overall Length (in)	7.06 in
Bore Diameter (in)	1.6875 in
Foot Height (in)	0.56 in
Overall Height to End Cap (in)	3 in
Length Through Bore (in)	2.00 in
Bolt Spacing (in)	5.8438 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Two Bolt
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	2.9375 in
Ability to Relubricate	Yes
Cage Type	Land Riding Retainer
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Material	52100 Bearing Steel
Housing Coating	Powder Coated
Bearing Insert Finish	Black Oxide
Radial Clearance	Standard
Housing Material	Cast Iron
Lubricant	Lithium Complex NLGI 2 Grease
Static Load Rating (lb)	5,139 lb
Bearing Type	Standard Duty
Inner Ring Outside Diameter (in)	2.307 in
Max Operating Temperature (C)	104 °C
Insert	MH-27T
Maximum Speed (RPM)	3000 rpm
Grease Fitting Thread Size	1/4-28
Dynamic Load Rating (lb)	7,901 lb
End Cap Available	No
Max Operating Temperature (F)	220 °F
Size Code	2-111
Fixed vs. Expansion	Fixed
Shaft Locking Type	Concentric

General Specifications

UPC	662461340691
Weight	4.74 LB
Packaged Length	8.20 IN
Packaged Width	5.30 IN
Packaged Height	2.30 IN
HTC	8483.20.4040
Country of Origin	Mexico
