• Cast iron housed, extended inner ring bearing with ball riding nylon retainer
• Designed to accommodate optional closed or open end to allow users to better conform OSHA requirements for personal protection
• Skwezloc® Concentric locking for near perfect concentricity
• Single lip contact seal and flinger
• Supplied sealed for life with optional lubrication fitting in the box

Dimensions

Overall Width (in)	3.25 in
Bolt Size (in)	7/16 in
Overall Length (in)	5.56 in
Overall Height (in)	1.67 in
Bore Diameter (in)	1.1875 in
Foot Height (in)	0.53 in
Overall Height to End Cap (in)	2.42 in
Length Through Bore (in)	1.61 in
Bolt Spacing (in)	4.596 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Setscrew Torque (in-lbs)	85 in/lbs
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	2.23 in
Vibration Frequency Inner Ring Defect	0.0905 cps
Inner Ring Outside Diameter (in)	1.586 in
Shaft Locking Type	Concentric
Maximum Speed (RPM)	4500 rpm
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Type	Standard Duty
Static Load Rating (lb)	2,567 lb
Housing Material	Cast Iron
Size Code	206
Cage Type	Land Riding Retainer
Bearing Insert Finish	Black Oxide
Radial Clearance	Standard
Insert	MH-19T
Dynamic Load Rating (lb)	4,390 lb
Vibration Frequency Roller Spin	0.0385 cps
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Fundamental Train	0.0067 cps
Vibration Frequency Outer Ring Defect	0.0595 cps
Housing Coating	Powder Coated
Lubricant	Lithium Complex NLGI 2 Grease
Grease Fitting Thread Size	1/4-28
Max Operating Temperature (F)	220 °F
End Cap Available	No

General Specifications

UPC	662461340653
Weight	2.21 LB
Packaged Length	6.10 IN
Packaged Width	3.70 IN
Packaged Height	1.70 IN
HTC	8483.20.4040
Country of Origin	Mexico
