• Cast iron housed, extended inner ring bearing with ball riding nylon retainer
• Designed to accommodate optional closed or open end to allow users to better conform OSHA requirements for personal protection
• Skwezloc® Concentric locking for near perfect concentricity
• Single lip contact seal and flinger
• Supplied sealed for life with optional lubrication fitting in the box

Dimensions

Overall Width (in)	2.75 in
Bolt Size (in)	7/16 in
Overall Height (in)	1.498 in
Overall Length (in)	4.88 in
Bore Diameter (in)	1 in
Overall Height to End Cap (in)	2.3 in
Foot Height (in)	0.53 in
Length Through Bore (in)	1.48 in
Bolt Spacing (in)	3.8891 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Two Bolt
Housing Style	Flange Block
Locking Collar Outside Diameter (in)	1.98 in
Setscrew Torque (in-lbs)	85 in/lbs
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Housing Material	Cast Iron
Inner Ring Outside Diameter (in)	1.938 in
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Material	52100 Bearing Steel
End Cap Available	No
Fixed vs. Expansion	Fixed
Grease Fitting Thread Size	1/4-28
Shaft Locking Type	Set Screw
Vibration Frequency Roller Spin	0.0442 cps
Vibration Frequency Outer Ring Defect	0.0682 cps
Housing Coating	Powder Coated
Insert	MH-16T
Bearing Type	Standard Duty
Dynamic Load Rating (lb)	2,801 lb
Size Code	2-015
Static Load Rating (lb)	1,651 lb
Vibration Frequency Inner Ring Defect	0.0985 cps
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Finish	Black Oxide
Maximum Speed (RPM)	5500 rpm
Max Operating Temperature (F)	220 °F
Vibration Frequency Fundamental Train	0.0068 cps
Radial Clearance	Standard
Cage Type	Land Riding Retainer

General Specifications

UPC	662461340646
Weight	1.47 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	Mexico
