• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	5/8 in
Overall Width (in)	5.25 in
Overall Length (in)	8.5 in
Overall Height (in)	2.38 in
Bore Diameter (in)	2 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.25 in
Bolt Spacing (in)	7.2500 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	3.50 in
Inner Race Heat Treat Method	Zone-Hardened
Radial Clearance	Standard
Bearing Type	Standard Duty
Maximum Speed (RPM)	4500 rpm
Size Code	2-23
Lubricant	Lithium Complex NLGI 2 Grease
Dynamic Load Rating (lb)	9,752 lb
Shaft Locking Type	Concentric
Static Load Rating (lb)	6,601 lb
Housing Coating	Powder Coated
Bearing Insert Finish	Black Oxide
Housing Material	Cast Iron
Max Operating Temperature (F)	220 °F
Misalignment Capability	±2.0° Misalignment - Static Only
Cage Type	Land Riding Retainer
Insert	2-2T
Bearing Insert Material	52100 Bearing Steel
End Cap Available	No
Fixed vs. Expansion	Fixed
Max Operating Temperature (C)	104 °C

General Specifications

UPC	662461030455
Weight	8.90 LB
Packaged Length	8.44 IN
Packaged Width	5.50 IN
Packaged Height	2.50 IN
HTC	8483.20.4040
Country of Origin	Mexico
