• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• Extra low drag seal cut down felt labyrinth seal and flinger
• Nylon retainer to reduce overall drag
• Oil lubricated and supplied with an adapter and plug for easy field relubrication
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation
• Looser than standard housing fit for ease of alignment on lightweight frames

Dimensions

Overall Width (in)	4.38 in
Bolt Size (in)	9/16 in
Overall Length (in)	7.06 in
Overall Height (in)	2.047 in
Bore Diameter (in)	1.75 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.938 in
Bolt Spacing (in)	5.8438 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Options	Extra Low Drag
Misalignment Type	Static Only
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Labryinth Seal
Housing Type	Flange, Two Bolt
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	7,901 lb
Housing Material	Cast Iron
End Cap Available	No
Max Operating Temperature (F)	220 °F
Bearing Type	Standard Duty
Fixed vs. Expansion	Fixed
Grease Fitting Thread Size	1/4-28
Insert	2-112 XLO
Inner Ring Outside Diameter (in)	2.297 in
Static Load Rating (lb)	5,139 lb
Bearing Insert Material	52100 Bearing Steel
Max Operating Temperature (C)	104 °C
Misalignment Capability	±2.0° Misalignment - Static Only
Lubricant	Oil Coated Only - No Factory Grease Fill
Maximum Speed (RPM)	1500 rpm
Housing Coating	Powder Coated
Shaft Locking Type	Set Screw
Bearing Insert Finish	Black Oxide
Radial Clearance	Standard
Size Code	2-111

General Specifications

UPC	662461322659
Weight	5.00 LB
Packaged Length	4.63 IN
Packaged Width	2.31 IN
Packaged Height	7.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
