• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	1/2 in
Overall Width (in)	4.13 in
Overall Height (in)	2.016 in
Overall Length (in)	6.75 in
Bore Diameter (in)	1.5 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.938 in
Bolt Spacing (in)	5.6363 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Maximum Speed (RPM)	4150 rpm
Size Code	2-19
Dynamic Load Rating (lb)	7,340 lb
Lubricant	Lithium Complex NLGI 2 Grease
Insert	2-18
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Coating	Powder Coated
Housing Material	Cast Iron
Inner Ring Outside Diameter (in)	2.063 in
Bearing Type	Standard Duty
Static Load Rating (lb)	4,467 lb
Max Operating Temperature (F)	220 °F
Shaft Locking Type	Set Screw
Grease Fitting Thread Size	1/4-28
End Cap Available	No
Bearing Insert Finish	Black Oxide
Bearing Insert Material	52100 Bearing Steel
Cage Type	Land Riding Retainer
Radial Clearance	Standard

General Specifications

UPC	662461004371
Weight	4.24 LB
Packaged Length	2.06 IN
Packaged Width	4.38 IN
Packaged Height	6.81 IN
HTC	8483.20.4040
Country of Origin	Mexico
