• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• Extra low drag seal cut down felt labyrinth seal and flinger
• Nylon retainer to reduce overall drag
• Oil lubricated and supplied with an adapter and plug for easy field relubrication
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation
• Looser than standard housing fit for ease of alignment on lightweight frames

Dimensions

Bolt Size (in)	1/2 in
Overall Width (in)	3.75 in
Overall Length (in)	6.13 in
Overall Height (in)	1.75 in
Bore Diameter (in)	1.4375 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.688 in
Bolt Spacing (in)	5.1250 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Options	Extra Low Drag
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Labryinth Seal
Housing Type	Flange, Two Bolt
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Setscrew Torque (in-lbs)	125-165 in/lbs
Ability to Relubricate	Yes
Misalignment Capability	±2.0° Misalignment - Static Only
Max Operating Temperature (F)	220 °F
Vibration Frequency Outer Ring Defect	0.0595 cps
Grease Fitting Thread Size	1/4-28
Bearing Type	Standard Duty
Maximum Speed (RPM)	1850 rpm
Bearing Insert Finish	Black Oxide
Housing Coating	Powder Coated
Static Load Rating (lb)	3,493 lb
Vibration Frequency Roller Spin	0.0386 cps
Fixed vs. Expansion	Fixed
End Cap Available	No
Vibration Frequency Fundamental Train	0.0066 cps
Dynamic Load Rating (lb)	5,782 lb
Cage Type	Land Riding Retainer
Insert	2-17 XLO
Housing Material	Cast Iron
Size Code	2-17
Bearing Insert Material	52100 Bearing Steel
Shaft Locking Type	Set Screw
Radial Clearance	Standard
Vibration Frequency Inner Ring Defect	0.0905 cps
Inner Ring Outside Diameter (in)	1.859 in
Lubricant	Oil Coated Only - No Factory Grease Fill

General Specifications

UPC	662461322574
Weight	3.20 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8483.20.4040
Country of Origin	United States of America
