• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Air Handling noise check for quiet operation
• Looser than standard housing fit for ease of alignment on lightweight frames
• Felt labyrinth seal and flinger for dusty and dirty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	3.75 in
Bolt Size (in)	1/2 in
Overall Length (in)	6.13 in
Overall Height (in)	1.81 in
Bore Diameter (in)	1.25 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.81 in
Bolt Spacing (in)	5.1250 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Bore Shape	Straight
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Options	Air Handling Housing Fit, Noise Tested
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	2.56 in
Bearing Type	Standard Duty
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Inner Ring Defect	0.0905 cps
Max Operating Temperature (F)	220 °F
Vibration Frequency Roller Spin	0.0386 cps
Housing Material	Cast Iron
Vibration Frequency Outer Ring Defect	0.0595 cps
Bearing Insert Finish	Black Oxide
Housing Coating	Powder Coated
Vibration Frequency Fundamental Train	0.0066 cps
Fixed vs. Expansion	Fixed
Dynamic Load Rating (lb)	5,782 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Static Load Rating (lb)	3,493 lb
End Cap Available	No
Cage Type	Land Riding Retainer
Radial Clearance	Standard
Shaft Locking Type	Concentric
Size Code	2-17
Maximum Speed (RPM)	6500 rpm
Insert	2-14T CXU
Inner Ring Outside Diameter (in)	1.859 in
Grease Fitting Thread Size	1/4-28
Lubricant	Lithium Complex NLGI 2 Grease

General Specifications

UPC	662461392300
Weight	3.50 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8483.20.4040
Country of Origin	United States of America
