• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal with black oxide bearing races
• Metric fitting and mounting bolts
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	9/16 in
Overall Width (in)	4.38 in
Bolt Size (mm)	M14 mm
Overall Height (in)	2.11 in
Overall Length (in)	7.06 in
Bore Diameter (mm)	45 mm
Foot Height (in)	0.56 in
Length Through Bore (in)	1.930 in
Bolt Spacing (in)	5.8438 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Two Bolt
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Insert	5209TMC
Radial Clearance	Standard
End Cap Available	No
Size Code	2-111
Cage Type	Land Riding Retainer
Housing Material	Cast Iron
Maximum Speed (RPM)	3800 rpm
Bearing Type	Standard Duty
Housing Coating	Powder Coated
Max Operating Temperature (F)	220 °F
Dynamic Load Rating (lb)	7,901 lb
Shaft Locking Type	Concentric
Bearing Insert Finish	Black Oxide
Static Load Rating (lb)	5,139 lb
Grease Fitting Thread Size	1/4-28
Max Operating Temperature (C)	104 °C
Bearing Insert Material	52100 Bearing Steel
Inner Ring Outside Diameter (in)	2.297 in
Lubricant	Lithium Complex NLGI 2 Grease

General Specifications

UPC	662461253953
Weight	5.00 LB
Packaged Length	4.63 IN
Packaged Width	2.31 IN
Packaged Height	7.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
