• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal with black oxide bearing races
• Metric fitting and mounting bolts
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	2.38 in
Bolt Size (in)	3/8 in
Overall Height (in)	1.39 in
Bolt Size (mm)	M10 mm
Overall Length (in)	4.41 in
Bore Diameter (mm)	20 mm
Foot Height (in)	0.44 in
Length Through Bore (in)	1.28 in
Bolt Spacing (in)	3.5310 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Locking Collar Outside Diameter (in)	1.75 in
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Vibration Frequency Fundamental Train	0.0066 cps
Maximum Speed (RPM)	6450 rpm
Vibration Frequency Outer Ring Defect	0.0593 cps
Vibration Frequency Roller Spin	0.0381 cps
Shaft Locking Type	Concentric
Housing Coating	Powder Coated
Grease Fitting Thread Size	1/4-28
Radial Clearance	Standard
Inner Ring Outside Diameter (in)	1.192 in
Static Load Rating (lb)	1,444 lb
Fixed vs. Expansion	Fixed
Cage Type	Land Riding Retainer
Bearing Type	Standard Duty
Max Operating Temperature (F)	220 °F
Size Code	2-012
Insert	5204TMC
Bearing Insert Finish	Black Oxide
Housing Material	Cast Iron
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Material	52100 Bearing Steel
Misalignment Capability	±2.0° Misalignment - Static Only
End Cap Available	No
Dynamic Load Rating (lb)	2,611 lb
Vibration Frequency Inner Ring Defect	0.0907 cps

General Specifications

UPC	662461253908
Weight	1.30 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8483.20.4040
Country of Origin	United States of America
