• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	3.25 in
Bolt Size (in)	7/16 in
Overall Height (in)	1.67 in
Overall Length (in)	5.56 in
Bore Diameter (in)	1.1875 in
Foot Height (in)	0.53 in
Length Through Bore (in)	1.61 in
Bolt Spacing (in)	4.5940 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Setscrew Torque (in-lbs)	85 in/lbs
Locking Collar Outside Diameter (in)	2.23 in
Lubricant	Lithium Complex NLGI 2 Grease
Housing Coating	Powder Coated
Vibration Frequency Inner Ring Defect	0.0905 cps
Inner Ring Outside Diameter (in)	1.587 in
Dynamic Load Rating (lb)	4,381 lb
Shaft Locking Type	Concentric
Bearing Type	Standard Duty
Housing Material	Cast Iron
Radial Clearance	Standard
Size Code	2-13
Fixed vs. Expansion	Fixed
Maximum Speed (RPM)	5450 rpm
Vibration Frequency Fundamental Train	0.0066 cps
Bearing Insert Material	52100 Bearing Steel
Insert	2-13TC
Static Load Rating (lb)	2,567 lb
Vibration Frequency Outer Ring Defect	0.0595 cps
Bearing Insert Finish	Black Oxide
Cage Type	Land Riding Retainer
Grease Fitting Thread Size	1/4-28
Vibration Frequency Roller Spin	0.0385 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Max Operating Temperature (F)	220 °F
End Cap Available	No

General Specifications

UPC	662461033401
Weight	2.40 LB
Packaged Length	3.50 IN
Packaged Width	1.69 IN
Packaged Height	5.75 IN
HTC	8483.20.4040
Country of Origin	United States of America
