• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew lock with corrosion resistant setscrews
• Zone hardened inner ring with 120° spacing setscrew lock with diamond faceted setscrews
• Single lip contact seal and flinger
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	7/16 in
Overall Width (in)	3.25 in
Overall Height (in)	1.563 in
Overall Length (in)	5.56 in
Bore Diameter (in)	1.125 in
Foot Height (in)	0.53 in
Length Through Bore (in)	1.5 in
Bolt Spacing (in)	4.594 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Two Bolt
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Setscrew Torque (in-lbs)	85 in/lbs
Ability to Relubricate	Yes
Maximum Speed (RPM)	5450 rpm
End Cap Available	No
Shaft Locking Type	Set Screw
Vibration Frequency Roller Spin	0.0385 cps
Insert	2-12C
Dynamic Load Rating (lb)	4,381 lb
Vibration Frequency Inner Ring Defect	0.0905 cps
Bearing Insert Material	52100 Bearing Steel
Bearing Insert Finish	Black Oxide
Bearing Type	Standard Duty
Max Operating Temperature (F)	220 °F
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Cage Type	Land Riding Retainer
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Outer Ring Defect	0.0595 cps
Size Code	2-13
Static Load Rating (lb)	2,567 lb
Inner Ring Outside Diameter (in)	1.587 in
Housing Coating	Powder Coated
Vibration Frequency Fundamental Train	0.0066 cps
Grease Fitting Thread Size	1/4-28
Radial Clearance	Standard
Housing Material	Cast Iron

General Specifications

UPC	662461022603
Weight	2.59 LB
Packaged Length	3.50 IN
Packaged Width	1.69 IN
Packaged Height	5.75 IN
HTC	8483.20.4040
Country of Origin	United States of America
