• Cast iron housed, extended inner ring bearing with ball riding nylon retainer
• Designed to accommodate optional closed or open end to allow users to better conform OSHA requirements for personal protection
• Skwezloc® Concentric locking for near perfect concentricity
• Single lip contact seal and flinger
• Supplied sealed for life with optional lubrication fitting in the box

Dimensions

Overall Width (in)	4.63 in
Bolt Size (in)	1/2 in
Overall Height (in)	1.81 in
Overall Length (in)	4.63 in
Bore Diameter (in)	1.4375 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.75 in
Bolt Spacing (in)	3.6250 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	Single Lip Contact Seal with Flinger
Housing Style	Flange Block
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	2.56 in
Inner Race Heat Treat Method	Zone-Hardened
Misalignment Capability	±2.0° Misalignment - Static Only
Shaft Locking Type	Concentric
Size Code	207
Grease Fitting Thread Size	M6X1
Lubricant	Lithium Complex NLGI 2 Grease
Radial Clearance	Standard
Fixed vs. Expansion	Fixed
Maximum Speed (RPM)	4000 rpm
Insert	MH-23T
Cage Type	Land Riding Retainer
Static Load Rating (lb)	3,493 lb
Dynamic Load Rating (lb)	5,782 lb
Inner Ring Outside Diameter (in)	1.86 in
End Cap Available	No
Bearing Insert Material	52100 Bearing Steel
Bearing Type	Standard Duty
Bearing Insert Finish	Black Oxide
Max Operating Temperature (F)	220 °F
Housing Coating	Powder Coated
Housing Material	Cast Iron

General Specifications

UPC	662461340776
Weight	3.79 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8483.20.4040
Country of Origin	Mexico
