• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	6.38 in
Bolt Size (in)	7/16 in
Overall Height (in)	2.33 in
Overall Length (in)	6.38 in
Bore Diameter (in)	2.1875 in
Pilot Diameter (in)	4.500 in
Foot Height (in)	0.44 in
Length Through Bore (in)	2.33 in
Housing Outside Diameter (in)	6.38 in
Bolt Circle (in)	5.375 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	Piloted
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Piloted
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Locking Collar Outside Diameter (in)	3.5 in
Inner Race Heat Treat Method	Zone-Hardened
Pilot Depth (in)	.625 in
Ability to Relubricate	Yes
Max Operating Temperature (F)	220 °F
Cage Type	Land Riding Retainer
Bearing Insert Finish	Black Oxide
Housing Material	Cast Iron
End Cap Available	No
Dynamic Load Rating (lb)	9,752 lb
Bearing Type	Standard Duty
Grease Fitting Thread Size	1/8 NPT
Housing Coating	Powder Coated
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Material	52100 Bearing Steel
Maximum Speed (RPM)	4500 rpm
Lubricant	Lithium Complex NLGI 2 Grease
Inner Ring Outside Diameter (in)	2.719 in
Static Load Rating (lb)	6,601 lb
Size Code	2-23
Shaft Locking Type	Concentric
Radial Clearance	Standard
Fixed vs. Expansion	Fixed
Insert	2-23T SFB

General Specifications

UPC	662461030288
Weight	7.39 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
