• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	6.13 in
Bolt Size (in)	7/16 in
Overall Height (in)	2.17 in
Overall Length (in)	6.13 in
Bore Diameter (in)	2 in
Foot Height (in)	0.44 in
Pilot Diameter (in)	4.25 in
Length Through Bore (in)	2.17 in
Housing Outside Diameter (in)	6.13 in
Bolt Circle (in)	5.125 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Flange, Piloted
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Pilot Depth (in)	0.44 in
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	3.35 in
Lubricant	Lithium Complex NLGI 2 Grease
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Radial Clearance	Standard
Housing Coating	Powder Coated
Inner Ring Outside Diameter (in)	2.469 in
Shaft Locking Type	Concentric
Insert	1-2T SFB
Vibration Frequency Inner Ring Defect	0.0984 cps
End Cap Available	No
Maximum Speed (RPM)	5000 rpm
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Roller Spin	0.0445 cps
Cage Type	Land Riding Retainer
Static Load Rating (lb)	5,216 lb
Max Operating Temperature (F)	220 °F
Vibration Frequency Outer Ring Defect	0.0683 cps
Grease Fitting Thread Size	1/8 NPT
Bearing Insert Finish	Black Oxide
Vibration Frequency Fundamental Train	0.0068 cps
Housing Material	Cast Iron
Size Code	2-115
Dynamic Load Rating (lb)	7,889 lb
Bearing Type	Standard Duty

General Specifications

UPC	662461043318
Weight	6.58 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
