• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	7/16 in
Overall Width (in)	6.13 in
Overall Height (in)	2.03 in
Overall Length (in)	6.13 in
Bore Diameter (in)	2 in
Foot Height (in)	0.44 in
Pilot Diameter (in)	4.25 in
Length Through Bore (in)	2.029 in
Housing Outside Diameter (in)	6.13 in
Bolt Circle (in)	5.125 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Piloted
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Pilot Depth (in)	0.44 in
Ability to Relubricate	Yes
Bearing Insert Material	52100 Bearing Steel
Radial Clearance	Standard
Inner Ring Outside Diameter (in)	2.469 in
Cage Type	Land Riding Retainer
Vibration Frequency Fundamental Train	0.0068 cps
Fixed vs. Expansion	Fixed
End Cap Available	No
Misalignment Capability	±2.0° Misalignment - Static Only
Max Operating Temperature (F)	220 °F
Shaft Locking Type	Set Screw
Maximum Speed (RPM)	3550 rpm
Vibration Frequency Roller Spin	0.0445 cps
Insert	1-2 SFB
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Outer Ring Defect	0.0683 cps
Dynamic Load Rating (lb)	7,889 lb
Vibration Frequency Inner Ring Defect	0.0984 cps
Housing Coating	Powder Coated
Static Load Rating (lb)	5,216 lb
Housing Material	Cast Iron
Size Code	2-115
Bearing Insert Finish	Black Oxide
Bearing Type	Standard Duty
Grease Fitting Thread Size	1/8 NPT

General Specifications

UPC	662461004050
Weight	5.95 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
