• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	7/16 in
Overall Width (in)	6.13 in
Overall Length (in)	6.13 in
Overall Height (in)	2.03 in
Bore Diameter (in)	1.875 in
Pilot Diameter (in)	4.25 in
Foot Height (in)	0.44 in
Length Through Bore (in)	2.029 in
Housing Outside Diameter (in)	6.13 in
Bolt Circle (in)	5.125 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Piloted
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Pilot Depth (in)	0.44 in
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Housing Material	Cast Iron
Dynamic Load Rating (lb)	7,889 lb
Max Operating Temperature (F)	220 °F
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Finish	Black Oxide
Vibration Frequency Roller Spin	0.0445 cps
Vibration Frequency Fundamental Train	0.0068 cps
Lubricant	Lithium Complex NLGI 2 Grease
Inner Ring Outside Diameter (in)	2.469 in
Maximum Speed (RPM)	3550 rpm
Grease Fitting Thread Size	1/8 NPT
Housing Coating	Powder Coated
Radial Clearance	Standard
Shaft Locking Type	Set Screw
Fixed vs. Expansion	Fixed
Size Code	2-115
Cage Type	Land Riding Retainer
Static Load Rating (lb)	5,216 lb
Bearing Type	Standard Duty
Vibration Frequency Outer Ring Defect	0.0683 cps
End Cap Available	No
Insert	2-114 SFB
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Inner Ring Defect	0.0984 cps

General Specifications

UPC	662461004036
Weight	6.25 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
