• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	3/8 in
Overall Width (in)	5 in
Overall Length (in)	5 in
Overall Height (in)	1.69 in
Bore Diameter (in)	1.4375 in
Foot Height (in)	0.38 in
Pilot Diameter (in)	3.375 in
Length Through Bore (in)	1.688 in
Housing Outside Diameter (in)	5 in
Bolt Circle (in)	4.125 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	Piloted
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Piloted
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Pilot Depth (in)	0.38 in
Ability to Relubricate	Yes
End Cap Available	No
Size Code	2-17
Radial Clearance	Standard
Bearing Insert Finish	Black Oxide
Maximum Speed (RPM)	4650 rpm
Fixed vs. Expansion	Fixed
Vibration Frequency Inner Ring Defect	0.0905 cps
Vibration Frequency Fundamental Train	0.0066 cps
Max Operating Temperature (F)	220 °F
Grease Fitting Thread Size	1/4-28
Vibration Frequency Outer Ring Defect	0.0595 cps
Shaft Locking Type	Set Screw
Misalignment Capability	±2.0° Misalignment - Static Only
Dynamic Load Rating (lb)	5,782 lb
Housing Material	Cast Iron
Bearing Insert Material	52100 Bearing Steel
Housing Coating	Powder Coated
Insert	2-17 SFB
Vibration Frequency Roller Spin	0.0386 cps
Cage Type	Land Riding Retainer
Inner Ring Outside Diameter (in)	1.859 in
Bearing Type	Standard Duty
Static Load Rating (lb)	3,493 lb
Lubricant	Lithium Complex NLGI 2 Grease

General Specifications

UPC	662461003978
Weight	3.51 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8483.20.4040
Country of Origin	United States of America
