• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	5 in
Bolt Size (in)	3/8 in
Overall Height (in)	1.82 in
Overall Length (in)	5 in
Bore Diameter (in)	1.375 in
Pilot Diameter (in)	3.375 in
Foot Height (in)	0.38 in
Length Through Bore (in)	1.82 in
Housing Outside Diameter (in)	5 in
Bolt Circle (in)	4.125 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Piloted
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Locking Collar Outside Diameter (in)	2.5 in
Inner Race Heat Treat Method	Zone-Hardened
Pilot Depth (in)	0.38 in
Ability to Relubricate	Yes
Insert	2-16TC SFB
Static Load Rating (lb)	3,493 lb
Bearing Insert Finish	Black Oxide
Vibration Frequency Fundamental Train	0.0066 cps
Cage Type	Land Riding Retainer
Shaft Locking Type	Concentric
Housing Coating	Powder Coated
Grease Fitting Thread Size	1/4-28
End Cap Available	No
Dynamic Load Rating (lb)	5,782 lb
Bearing Insert Material	52100 Bearing Steel
Fixed vs. Expansion	Fixed
Vibration Frequency Inner Ring Defect	0.0905 cps
Size Code	2-17
Lubricant	Lithium Complex NLGI 2 Grease
Housing Material	Cast Iron
Radial Clearance	Standard
Maximum Speed (RPM)	4650 rpm
Vibration Frequency Outer Ring Defect	0.0595 cps
Vibration Frequency Roller Spin	0.0386 cps
Bearing Type	Standard Duty
Inner Ring Outside Diameter (in)	1.859 in
Misalignment Capability	±2.0° Misalignment - Static Only
Max Operating Temperature (F)	220 °F

General Specifications

UPC	662461033234
Weight	3.85 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8483.20.4040
Country of Origin	United States of America
