• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	7/16 in
Overall Width (in)	6.13 in
Bolt Size (mm)	M12 mm
Overall Height (in)	1.94 in
Overall Length (in)	6.13 in
Bore Diameter (mm)	45 mm
Foot Height (in)	0.44 in
Pilot Diameter (in)	4.25 in
Length Through Bore (in)	1.935 in
Bolt Circle (in)	5.125 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	Piloted
Housing Construction	One Piece
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Piloted
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Pilot Depth (in)	0.41 in
Ability to Relubricate	Yes
Lubricant	Lithium Complex NLGI 2 Grease
Housing Coating	Powder Coated
Static Load Rating (lb)	5,139 lb
Vibration Frequency Fundamental Train	0.0067 cps
Grease Fitting Thread Size	1/4-28
Shaft Locking Type	Set Screw
Vibration Frequency Outer Ring Defect	0.0673 cps
Insert	5209C
Fixed vs. Expansion	Fixed
Bearing Type	Standard Duty
Bearing Insert Finish	Black Oxide
Size Code	2-111
Max Operating Temperature (F)	220 °F
Dynamic Load Rating (lb)	7,901 lb
Vibration Frequency Roller Spin	0.0417 cps
Cage Type	Land Riding Retainer
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Material	Cast Iron
End Cap Available	No
Vibration Frequency Inner Ring Defect	0.0994 cps
Bearing Insert Material	52100 Bearing Steel
Maximum Speed (RPM)	3800 rpm
Inner Ring Outside Diameter (in)	2.297 in
Radial Clearance	Standard

General Specifications

UPC	662461054857
Weight	6.00 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
