• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal with black oxide bearing races
• Metric fitting and mounting bolts
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	5.25 in
Bolt Size (in)	3/8 in
Bolt Size (mm)	M10 mm
Overall Length (in)	5.25 in
Overall Height (in)	2 in
Bore Diameter (mm)	40 mm
Foot Height (in)	0.44 in
Pilot Diameter (in)	3.625 in
Length Through Bore (in)	2 in
Bolt Circle (in)	4.375 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Piloted
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Pilot Depth (in)	0.41 in
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Radial Clearance	Standard
Housing Coating	Powder Coated
End Cap Available	No
Bearing Insert Material	52100 Bearing Steel
Vibration Frequency Outer Ring Defect	0.0591 cps
Housing Material	Cast Iron
Dynamic Load Rating (lb)	7,340 lb
Cage Type	Land Riding Retainer
Vibration Frequency Inner Ring Defect	0.0909 cps
Inner Ring Outside Diameter (in)	2.063 in
Max Operating Temperature (F)	220 °F
Insert	5208TMC SFB
Vibration Frequency Fundamental Train	0.0066 cps
Grease Fitting Thread Size	1/4-28
Static Load Rating (lb)	4,467 lb
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Type	Standard Duty
Fixed vs. Expansion	Fixed
Shaft Locking Type	Concentric
Maximum Speed (RPM)	4150 rpm
Vibration Frequency Roller Spin	0.0376 cps
Size Code	2-19
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Finish	Black Oxide

General Specifications

UPC	662461254363
Weight	4.66 LB
Packaged Length	2.13 IN
Packaged Width	5.50 IN
Packaged Height	5.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
