• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal with black oxide bearing races
• Metric fitting and mounting bolts
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	5 in
Bolt Size (in)	3/8 in
Bolt Size (mm)	M10 mm
Overall Length (in)	5 in
Overall Height (in)	1.82 in
Bore Diameter (mm)	35 mm
Foot Height (in)	0.38 in
Pilot Diameter (in)	3.375 in
Length Through Bore (in)	1.82 in
Housing Outside Diameter (in)	5 in
Bolt Circle (in)	4.125 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Piloted
Housing Style	Flange Block
Ability to Relubricate	Yes
Pilot Depth (in)	0.38 in
Locking Collar Outside Diameter (in)	2.5 in
Inner Race Heat Treat Method	Zone-Hardened
Bearing Type	Standard Duty
Max Operating Temperature (F)	220 °F
Vibration Frequency Inner Ring Defect	0.0905 cps
Maximum Speed (RPM)	4650 rpm
Fixed vs. Expansion	Fixed
Insert	5207TMC SFB
Bearing Insert Material	52100 Bearing Steel
Bearing Insert Finish	Black Oxide
Vibration Frequency Fundamental Train	0.0066 cps
End Cap Available	No
Housing Coating	Powder Coated
Vibration Frequency Outer Ring Defect	0.0595 cps
Static Load Rating (lb)	3,493 lb
Inner Ring Outside Diameter (in)	1.859 in
Size Code	2-17
Radial Clearance	Standard
Vibration Frequency Roller Spin	0.0386 cps
Cage Type	Land Riding Retainer
Lubricant	Lithium Complex NLGI 2 Grease
Shaft Locking Type	Concentric
Housing Material	Cast Iron
Grease Fitting Thread Size	1/4-28
Misalignment Capability	±2.0° Misalignment - Static Only
Dynamic Load Rating (lb)	5,782 lb

General Specifications

UPC	662461254356
Weight	3.72 LB
Packaged Length	2.00 IN
Packaged Width	5.00 IN
Packaged Height	5.00 IN
HTC	8483.20.4040
Country of Origin	United States of America
