• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal with black oxide bearing races
• Metric fitting and mounting bolts
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	4.38 in
Bolt Size (in)	5/16 in
Overall Length (in)	4.38 in
Overall Height (in)	1.61 in
Bolt Size (mm)	M8 mm
Bore Diameter (mm)	30 mm
Foot Height (in)	0.38 in
Pilot Diameter (in)	3 in
Length Through Bore (in)	1.61 in
Housing Outside Diameter (in)	4.38 in
Bolt Circle (in)	3.625 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	Piloted
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Piloted
Housing Style	Flange Block
Pilot Depth (in)	0.25 in
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Maximum Speed (RPM)	5450 rpm
Size Code	2-13
End Cap Available	No
Bearing Insert Finish	Black Oxide
Radial Clearance	Standard
Vibration Frequency Fundamental Train	0.0066 cps
Bearing Type	Standard Duty
Vibration Frequency Roller Spin	0.0385 cps
Max Operating Temperature (F)	220 °F
Grease Fitting Thread Size	1/4-28
Bearing Insert Material	52100 Bearing Steel
Housing Coating	Powder Coated
Static Load Rating (lb)	2,567 lb
Housing Material	Cast Iron
Insert	5206TMC SFB
Vibration Frequency Outer Ring Defect	0.0595 cps
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	4,381 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Inner Ring Defect	0.0905 cps
Fixed vs. Expansion	Fixed
Inner Ring Outside Diameter (in)	1.594 in
Lubricant	Lithium Complex NLGI 2 Grease
Shaft Locking Type	Concentric

General Specifications

UPC	662461254349
Weight	2.93 LB
Packaged Length	4.50 IN
Packaged Width	1.69 IN
Packaged Height	4.56 IN
HTC	8483.20.4040
Country of Origin	United States of America
