• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	7.38 in
Bolt Size (in)	5/8 in
Overall Height (in)	3 in
Overall Length (in)	7.38 in
Bore Diameter (in)	2.5 in
Foot Height (in)	0.69 in
Length Through Bore (in)	2.748 in
Bolt Spacing (in)	5.8750 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	Brass
Housing Type	Flange, Four Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Setscrew Torque (in-lbs)	350-450 in/lbs
Ability to Relubricate	Yes
Radial Clearance	Standard
Maximum Speed (RPM)	2225 rpm
Housing Coating	Powder Coated
Bearing Insert Finish	Black Oxide
Bearing Type	Standard Duty
End Cap Available	No
Inner Ring Outside Diameter (in)	3.433 in
Insert	3-28C
Shaft Locking Type	Set Screw
Bearing Insert Material	52100 Bearing Steel
Lubricant	Lithium Complex NLGI 2 Grease
Static Load Rating (lb)	10,063 lb
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Cage Type	Land Riding Retainer
Grease Fitting Thread Size	1/8 NPT
Dynamic Load Rating (lb)	13,971 lb
Size Code	2-211
Max Operating Temperature (F)	220 °F
Housing Material	Cast Iron
Housing Backside Inner Diameter	5.13

General Specifications

UPC	662461022160
Weight	15.75 LB
Packaged Length	8.13 IN
Packaged Width	7.94 IN
Packaged Height	3.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
