• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	5/8 in
Overall Width (in)	6.88 in
Overall Height (in)	2.75 in
Overall Length (in)	6.88 in
Bore Diameter (in)	2.4375 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.83 in
Bolt Spacing (in)	5.6250 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Locking Collar Outside Diameter (in)	4.22 in
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Radial Clearance	Standard
Cage Type	Land Riding Retainer
Misalignment Capability	±2.0° Misalignment - Static Only
Size Code	2-27
Housing Material	Cast Iron
Housing Backside Inner Diameter	5
Shaft Locking Type	Concentric
Bearing Type	Standard Duty
Housing Coating	Powder Coated
Grease Fitting Thread Size	1/8 NPT
Lubricant	Lithium Complex NLGI 2 Grease
Maximum Speed (RPM)	2550 rpm
Max Operating Temperature (F)	220 °F
Dynamic Load Rating (lb)	11,789 lb
Bearing Insert Finish	Black Oxide
Insert	2-27TC
Inner Ring Outside Diameter (in)	2.981 in
End Cap Available	No
Static Load Rating (lb)	8,150 lb
Fixed vs. Expansion	Fixed
Bearing Insert Material	52100 Bearing Steel

General Specifications

UPC	662461033197
Weight	12.64 LB
Packaged Length	7.19 IN
Packaged Width	7.00 IN
Packaged Height	3.31 IN
HTC	8483.20.4040
Country of Origin	United States of America
