• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	6.88 in
Bolt Size (in)	5/8 in
Overall Length (in)	6.88 in
Overall Height (in)	2.688 in
Bore Diameter (in)	2.4375 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.559 in
Bolt Spacing (in)	5.6250 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Setscrew Torque (in-lbs)	250-300 in/lbs
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Static Load Rating (lb)	8,150 lb
Bearing Insert Finish	Black Oxide
Bearing Type	Standard Duty
Radial Clearance	Standard
Grease Fitting Thread Size	1/8 NPT
Insert	2-27C
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	11,789 lb
Max Operating Temperature (F)	220 °F
Housing Backside Inner Diameter	5
Lubricant	Lithium Complex NLGI 2 Grease
Fixed vs. Expansion	Fixed
Maximum Speed (RPM)	2550 rpm
Shaft Locking Type	Set Screw
Housing Coating	Powder Coated
Housing Material	Cast Iron
Size Code	2-27
Misalignment Capability	±2.0° Misalignment - Static Only
Inner Ring Outside Diameter (in)	2.981 in
End Cap Available	No
Bearing Insert Material	52100 Bearing Steel

General Specifications

UPC	662461022153
Weight	11.16 LB
Packaged Length	7.19 IN
Packaged Width	7.00 IN
Packaged Height	3.31 IN
HTC	8483.20.4040
Country of Origin	United States of America
