• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	6.38 in
Bolt Size (in)	5/8 in
Overall Height (in)	2.375 in
Overall Length (in)	6.38 in
Bore Diameter (in)	2.1875 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.33 in
Bolt Spacing (in)	5.1250 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	3.6 in
Inner Race Heat Treat Method	Zone-Hardened
Housing Material	Cast Iron
Housing Backside Inner Diameter	4.25
End Cap Available	No
Shaft Locking Type	Concentric
Cage Type	Land Riding Retainer
Bearing Insert Finish	Black Oxide
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Material	52100 Bearing Steel
Bearing Type	Standard Duty
Grease Fitting Thread Size	1/8 NPT
Radial Clearance	Standard
Housing Coating	Powder Coated
Maximum Speed (RPM)	4500 rpm
Static Load Rating (lb)	6,601 lb
Max Operating Temperature (F)	220 °F
Size Code	2-23
Insert	2-23T
Fixed vs. Expansion	Fixed
Inner Ring Outside Diameter (in)	2.723 in
Dynamic Load Rating (lb)	9,752 lb
Misalignment Capability	±2.0° Misalignment - Static Only

General Specifications

UPC	662461030110
Weight	10.62 LB
Packaged Length	6.50 IN
Packaged Width	6.75 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	Mexico
