• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	5/8 in
Overall Width (in)	6.38 in
Overall Length (in)	6.38 in
Overall Height (in)	2.313 in
Bore Diameter (in)	2 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.184 in
Bolt Spacing (in)	5.1250 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Bearing Insert Finish	Black Oxide
Static Load Rating (lb)	6,601 lb
Max Operating Temperature (F)	220 °F
Bearing Insert Material	52100 Bearing Steel
Dynamic Load Rating (lb)	9,752 lb
Size Code	2-23
Maximum Speed (RPM)	3250 rpm
Housing Coating	Powder Coated
Shaft Locking Type	Set Screw
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Type	Standard Duty
Housing Material	Cast Iron
Insert	2-2
Misalignment Capability	±2.0° Misalignment - Static Only
Cage Type	Land Riding Retainer
End Cap Available	No
Fixed vs. Expansion	Fixed
Grease Fitting Thread Size	1/8 NPT
Housing Backside Inner Diameter	4.25
Inner Ring Outside Diameter (in)	2.723 in
Radial Clearance	Standard

General Specifications

UPC	662461003602
Weight	10.37 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	Mexico
