• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	9/16 in
Overall Width (in)	5.38 in
Overall Length (in)	5.38 in
Overall Height (in)	2.167 in
Bore Diameter (in)	1.75 in
Foot Height (in)	0.56 in
Length Through Bore (in)	2.06 in
Bolt Spacing (in)	4.125 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	3 in
Inner Race Heat Treat Method	Zone-Hardened
Cage Type	Land Riding Retainer
Housing Coating	Powder Coated
Bearing Insert Finish	Black Oxide
Dynamic Load Rating (lb)	7,901 lb
Static Load Rating (lb)	5,139 lb
End Cap Available	No
Shaft Locking Type	Concentric
Radial Clearance	Standard
Inner Ring Outside Diameter (in)	2.307 in
Size Code	2-111
Bearing Type	Standard Duty
Grease Fitting Thread Size	1/4-28
Housing Material	Cast Iron
Insert	2-112TC
Fixed vs. Expansion	Fixed
Lubricant	Lithium Complex NLGI 2 Grease
Maximum Speed (RPM)	3800 rpm
Max Operating Temperature (F)	220 °F
Housing Backside Inner Diameter	3.88
Bearing Insert Material	52100 Bearing Steel
Misalignment Capability	±2.0° Misalignment - Static Only

General Specifications

UPC	662461033128
Weight	6.06 LB
Packaged Length	6.06 IN
Packaged Width	5.94 IN
Packaged Height	2.19 IN
HTC	8483.20.4040
Country of Origin	United States of America
