• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	5.13 in
Bolt Size (in)	1/2 in
Overall Length (in)	5.13 in
Overall Height (in)	2.016 in
Bore Diameter (in)	1.5625 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.938 in
Bolt Spacing (in)	4.0000 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Bearing Insert Material	52100 Bearing Steel
Inner Ring Outside Diameter (in)	2.07 in
Shaft Locking Type	Set Screw
Dynamic Load Rating (lb)	7,340 lb
Insert	2-19
Maximum Speed (RPM)	4150 rpm
End Cap Available	No
Housing Coating	Powder Coated
Max Operating Temperature (F)	220 °F
Fixed vs. Expansion	Fixed
Grease Fitting Thread Size	1/4-28
Housing Backside Inner Diameter	3.5
Housing Material	Cast Iron
Bearing Type	Standard Duty
Radial Clearance	Standard
Lubricant	Lithium Complex NLGI 2 Grease
Bearing Insert Finish	Black Oxide
Static Load Rating (lb)	4,467 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Cage Type	Land Riding Retainer
Size Code	2-19

General Specifications

UPC	662461003527
Weight	5.00 LB
Packaged Length	5.50 IN
Packaged Width	2.13 IN
Packaged Height	5.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
