• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	5.13 in
Bolt Size (in)	1/2 in
Overall Length (in)	5.13 in
Overall Height (in)	2.0781 in
Bore Diameter (in)	1.5 in
Foot Height (in)	0.56 in
Length Through Bore (in)	2 in
Bolt Spacing (in)	4.0000 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	Felt Labyrinth Seal
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	2.75 in
Ability to Relubricate	Yes
Dynamic Load Rating (lb)	7,340 lb
Bearing Type	Standard Duty
Static Load Rating (lb)	4,467 lb
Maximum Speed (RPM)	5850 rpm
Fixed vs. Expansion	Fixed
Radial Clearance	Standard
Bearing Insert Material	52100 Bearing Steel
Shaft Locking Type	Concentric
Inner Ring Outside Diameter (in)	2.07 in
Grease Fitting Thread Size	1/4-28
Bearing Insert Finish	Black Oxide
Lubricant	Lithium Complex NLGI 2 Grease
Size Code	2-19
End Cap Available	No
Cage Type	Land Riding Retainer
Max Operating Temperature (F)	220 °F
Housing Material	Cast Iron
Housing Backside Inner Diameter	3.5
Insert	AR-2-18T
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Coating	Powder Coated

General Specifications

UPC	662461030042
Weight	5.35 LB
Packaged Length	2.13 IN
Packaged Width	5.50 IN
Packaged Height	5.50 IN
HTC	8483.20.4040
Country of Origin	Mexico
