• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• High temperature felt labyrinth seal and flinger for dry and dusty environment
• Increased internal clearance and high temperature grease
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	4.63 in
Bolt Size (in)	1/2 in
Overall Length (in)	4.63 in
Overall Height (in)	1.75 in
Bore Diameter (in)	1.4375 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.69 in
Bolt Spacing (in)	3.6250 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Misalignment Type	Static Only
Options	High Temperature
Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	High Temp Labyrinth
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Bearing Insert Material	52100 Bearing Steel
Static Load Rating (lb)	3,493 lb
Shaft Locking Type	Set Screw
Bearing Insert Finish	Black Oxide
Grease Fitting Thread Size	1/4-28
Vibration Frequency Roller Spin	0.0386 cps
Bearing Type	Standard Duty
Dynamic Load Rating (lb)	5,782 lb
Vibration Frequency Fundamental Train	0.0066 cps
Fixed vs. Expansion	Fixed
Inner Ring Outside Diameter (in)	1.86 in
Maximum Speed (RPM)	2200 rpm
Insert	2-17 HT
End Cap Available	No
Housing Coating	Powder Coated
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Backside Inner Diameter	3.31
Max Operating Temperature (F)	400 °F
Housing Material	Cast Iron
Lubricant	Lithium Complex Grease With Synthetic Oil
Vibration Frequency Inner Ring Defect	0.0905 cps
Vibration Frequency Outer Ring Defect	0.0595 cps
Size Code	2-17
Cage Type	Land Riding Retainer
Radial Clearance	Increased

General Specifications

UPC	662461314913
Weight	4.10 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8483.20.4040
Country of Origin	United States of America
