• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Thread Size	1 1/4-11 1/2
Overall Width (in)	2.56 in
Overall Height (in)	6.81 in
Overall Length (in)	5.63 in
Base Width (in)	2.31 in
Bore Diameter (in)	2.4375 in
Base to Center Height (in)	4 in
Thread Depth (in)	1.13 in
Length Through Bore (in)	2.559 in
Centerline to Outermost Bearing Face (in)	1.56 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Options	High Contamination
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Series	SEHB
Seal Type	Felt Labyrinth Seal
Housing Type	Hanger Unit
Housing Style	Hanger Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Vibration Frequency Inner Ring Defect	0.0989 cps
Vibration Frequency Fundamental Train	0.0068 cps
Grease Fitting Thread Size	1/8 NPT
Inner Ring Outside Diameter (in)	2.981 in
Radial Clearance	Standard
Maximum Speed (RPM)	3000 rpm
Housing Material	Cast Iron
Dynamic Load Rating (lb)	11,789 lb
Vibration Frequency Outer Ring Defect	0.0678 cps
Shaft Locking Type	Set Screw
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Size Code	2-27
Max Operating Temperature (F)	220 °F
Cage Type	Land Riding Retainer
Bearing Insert Finish	Black Oxide
End Cap Available	No
Bearing Insert Material	52100 Bearing Steel
Housing Coating	Powder Coated
Bearing Type	Standard Duty
Static Load Rating (lb)	8,150 lb
Insert	2-27
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Roller Spin	0.0432 cps
Housing Width (in)	1.44 in

General Specifications

UPC	662461334997
Weight	9.00 LB
Packaged Length	6.88 IN
Packaged Width	6.88 IN
Packaged Height	2.63 IN
HTC	8483.20.4040
Country of Origin	United States of America
