• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Thread Size	3/4-14
Overall Width (in)	1.94 in
Overall Height (in)	4.75 in
Base Width (in)	1.56 in
Overall Length (in)	3.75 in
Bore Diameter (in)	1.5 in
Base to Center Height (in)	2.875 in
Thread Depth (in)	0.75 in
Length Through Bore (in)	1.938 in
Centerline to Outermost Bearing Face (in)	1.18 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Housing Construction	One Piece
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Series	SEHB
Seal Type	Single Lip Contact Seal
Housing Type	Hanger Unit
Housing Style	Hanger Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
End Cap Available	No
Bearing Type	Standard Duty
Vibration Frequency Inner Ring Defect	0.0909 cps
Housing Material	Cast Iron
Bearing Insert Finish	Black Oxide
Fixed vs. Expansion	Fixed
Cage Type	Land Riding Retainer
Vibration Frequency Outer Ring Defect	0.0591 cps
Dynamic Load Rating (lb)	7,340 lb
Shaft Locking Type	Set Screw
Maximum Speed (RPM)	4150 rpm
Insert	2-18C
Vibration Frequency Roller Spin	0.0376 cps
Vibration Frequency Fundamental Train	0.0066 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Radial Clearance	Standard
Bearing Insert Material	52100 Bearing Steel
Size Code	2-19
Inner Ring Outside Diameter (in)	2.07 in
Static Load Rating (lb)	4,467 lb
Max Operating Temperature (F)	220 °F
Housing Coating	Powder Coated
Lubricant	Lithium Complex NLGI 2 Grease
Grease Fitting Thread Size	1/4-28
Housing Width (in)	1.25 in

General Specifications

UPC	662461021637
Weight	3.45 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8483.20.4040
Country of Origin	United States of America
