• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Thread Size	3/4 - 14
Overall Height (in)	4.06 in
Overall Width (in)	1.56 in
Overall Length (in)	3.13 in
Base Width (in)	1.56 in
Bore Diameter (mm)	30 mm
Base to Center Height (in)	2.5 in
Thread Depth (in)	0.81 in
Length Through Bore (in)	1.498 in
Centerline to Outermost Bearing Face (in)	0.87 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Series	CSCHB
Housing Type	Hanger Unit
Seal Type	Felt Labyrinth Seal
Housing Style	Hanger Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Roller Spin	0.0385 cps
Max Operating Temperature (F)	220 °F
Cage Type	Land Riding Retainer
Shaft Locking Type	Set Screw
Static Load Rating (lb)	2,567 lb
Inner Ring Outside Diameter (in)	1.594 in
End Cap Available	No
Vibration Frequency Inner Ring Defect	0.0905 cps
Dynamic Load Rating (lb)	4,381 lb
Bearing Insert Material	52100 Bearing Steel
Bearing Insert Finish	Black Oxide
Fixed vs. Expansion	Fixed
Maximum Speed (RPM)	5405 rpm
Insert	5206
Housing Material	Cast Iron
Size Code	2-13
Grease Fitting Thread Size	1/4-28
Radial Clearance	Standard
Bearing Type	Standard Duty
Vibration Frequency Fundamental Train	0.0066 cps
Housing Coating	Powder Coated
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Outer Ring Defect	0.0595 cps
Housing Width (in)	0.94 in

General Specifications

UPC	662461052129
Weight	2.20 LB
Packaged Length	4.50 IN
Packaged Width	1.69 IN
Packaged Height	4.56 IN
HTC	8483.20.4040
Country of Origin	United States of America
