• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	2.19 in
Overall Height (in)	4.94 in
Overall Length (in)	4.94 in
Bore Diameter (in)	2.1875 in
Length Through Bore (in)	2.188 in
Centerline to Outermost Bearing Face (in)	1.31 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Construction	One Piece
Bore Shape	Straight
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Gray
Series	SC
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Cartridge, Cylindrical
Seal Type	Single Lip Contact Seal
Housing Style	Cartridge Block
Outside Diameter (in)	4.938
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Grease Fitting Thread Size	1/4-28
Size Code	2-23
Radial Clearance	Standard
End Cap Available	No
Static Load Rating (lb)	6,601 lb
Housing Material	Cast Iron
Cage Type	Land Riding Retainer
Bearing Insert Material	52100 Bearing Steel
Shaft Locking Type	Set Screw
Insert	2-23C
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Finish	Black Oxide
Dynamic Load Rating (lb)	9,752 lb
Lubricant	Lithium Complex NLGI 2 Grease
Maximum Speed (RPM)	3250 rpm
Bearing Type	Standard Duty
Inner Ring Outside Diameter (in)	2.719 in
Max Operating Temperature (F)	220 °F
Housing Width (in)	1.59 in

General Specifications

UPC	662461021200
Weight	5.60 LB
Packaged Length	5.50 IN
Packaged Width	5.38 IN
Packaged Height	3.50 IN
HTC	8482.10.5052
Country of Origin	Mexico
