• Powder coated epoxy cast iron cylindrical O.D. housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Felt labyrinth seal and flinger for dry and dusty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Length (in)	4.38 in
Overall Height (in)	4.38 in
Overall Width (in)	2 in
Bore Diameter (in)	1.6875 in
Length Through Bore (in)	2 in
Centerline to Outermost Bearing Face (in)	1.25 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Gray
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Series	SC-T
Housing Type	Cartridge, Cylindrical
Seal Type	Felt Labyrinth Seal
Housing Style	Cartridge Block
Outside Diameter (in)	4.375
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	3 in
Inner Ring Outside Diameter (in)	2.297 in
Lubricant	Lithium Complex NLGI 2 Grease
Dynamic Load Rating (lb)	7,901 lb
Shaft Locking Type	Concentric
Fixed vs. Expansion	Fixed
Static Load Rating (lb)	5,139 lb
Bearing Insert Finish	Black Oxide
Size Code	2-111
Maximum Speed (RPM)	5300 rpm
Housing Material	Cast Iron
Bearing Insert Material	52100 Bearing Steel
Cage Type	Land Riding Retainer
Radial Clearance	Standard
Max Operating Temperature (F)	220 °F
End Cap Available	No
Bearing Type	Standard Duty
Insert	2-111T
Misalignment Capability	±2.0° Misalignment - Static Only
Grease Fitting Thread Size	1/4-28
Housing Width (in)	1.44 in

General Specifications

UPC	662461029879
Weight	4.55 LB
Packaged Length	5.00 IN
Packaged Width	2.00 IN
Packaged Height	5.00 IN
HTC	8482.10.5052
Country of Origin	Mexico
