• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Zone hardened inner ring with 120° spacing setscrew lock with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	1.5 in
Overall Length (in)	3.5 in
Overall Height (in)	3.5 in
Bore Diameter (in)	1.1875 in
Length Through Bore (in)	1.5 in
Centerline to Outermost Bearing Face (in)	0.87 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Gray
Outer Ring Land Profile	Standard
Series	SC
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Cartridge, Cylindrical
Seal Type	Felt Labyrinth Seal
Housing Style	Cartridge Block
Outside Diameter (in)	3.5
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Maximum Speed (RPM)	5450 rpm
Radial Clearance	Standard
End Cap Available	No
Fixed vs. Expansion	Fixed
Cage Type	Land Riding Retainer
Bearing Insert Material	52100 Bearing Steel
Static Load Rating (lb)	2,567 lb
Insert	2-13
Bearing Type	Standard Duty
Inner Ring Outside Diameter (in)	1.594 in
Grease Fitting Thread Size	1/4-28
Housing Material	Cast Iron
Shaft Locking Type	Set Screw
Dynamic Load Rating (lb)	4,381 lb
Max Operating Temperature (F)	220 °F
Lubricant	Lithium Complex NLGI 2 Grease
Size Code	2-13
Bearing Insert Finish	Black Oxide
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Width (in)	1.09 in

General Specifications

UPC	662461002421
Weight	2.19 LB
Packaged Length	4.00 IN
Packaged Width	1.50 IN
Packaged Height	3.94 IN
HTC	8482.10.5052
Country of Origin	Mexico
