• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	1.38 in
Overall Height (in)	3.13 in
Overall Length (in)	3.13 in
Bore Diameter (in)	1 in
Length Through Bore (in)	1.375 in
Centerline to Outermost Bearing Face (in)	0.81 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Construction	One Piece
Bore Shape	Straight
Housing Color	Gray
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Series	SC
Seal Type	Single Lip Contact Seal
Housing Type	Cartridge, Cylindrical
Outside Diameter (in)	3.125
Housing Style	Cartridge Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Size Code	2-015
Grease Fitting Thread Size	1/4-28
Fixed vs. Expansion	Fixed
Bearing Insert Finish	Black Oxide
Radial Clearance	Standard
Inner Ring Outside Diameter (in)	1.375 in
Shaft Locking Type	Set Screw
Dynamic Load Rating (lb)	2,801 lb
Static Load Rating (lb)	1,651 lb
End Cap Available	No
Max Operating Temperature (F)	220 °F
Cage Type	Land Riding Retainer
Lubricant	Lithium Complex NLGI 2 Grease
Housing Material	Cast Iron
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Type	Standard Duty
Insert	2-1C
Maximum Speed (RPM)	6350 rpm
Bearing Insert Material	52100 Bearing Steel
Housing Width (in)	1.03 in

General Specifications

UPC	662461021002
Weight	1.65 LB
Packaged Length	3.13 IN
Packaged Width	1.75 IN
Packaged Height	3.13 IN
HTC	8482.10.5048
Country of Origin	Mexico
