• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Fluoropolymer-coated 4-bolt split cast iron housing for improved corrosion resistance
• USDA H-1 approved Food-grade grease

Dimensions

Bolt Size (in)	0.875 in
Overall Length (in)	18.5 in
Bolt Center-to-Center Length (in)	14.69 in
Overall Width (in)	6.2 in
Overall Height (in)	11 in
Base Width (in)	5.125 in
Bore Size (in)	4.9375 in
Centerline to Front Face (in)	3.625 in
Inner Race Length (in)	6.203 in
Bolt Center Min (in)	13.5 in
Bolt Center Max (in)	15.875 in
Foot Height (in)	3.125 in
Base to Center Height (in)	5.5 in
Collar Outer Diameter (in)	7.313 in

Technical Specifications

Insert Material	52100 Bearing Steel
Expansion	No
Housing Base	Solid
Housing Type	Pillow Block, Four Bolt
Rolling Element	Tapered Roller
Measure Units	Inch
Seal Type	Single Lip Contact Seal
Housing Material	Flouropolymer Coated Cast Iron
Locking Type	Collar Mount
Internal Clearance	Standard
Bore Shape	Straight
Misalignment	±3.0° Misalignment - Static Only
Speed (Max)	1000
Radial Dynamic Load Capacity (lb)	35,520 lb
Housing Construction	Split Two Piece
Misalignment Type	Static Only
Bearing Insert Coating	Uncoated
Platform	CR Series
End Cap	No
Retainer Material	Steel
Replaceable Insert	Yes
Housing Color	Silver/Gray
Outer Ring Land Profile	Standard
Options	Corrosion Resistant
Series	RPBA
Grease Fitting Thread Size	1/8 NPT
Housing Style	Pillow Block
Insert Number	RCIA-415C FG1
Maximum Operating Temperature (F)	220 °F
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Case Carburized Inner Ring
Lubrication Type	Lithium; EP; NLGI#2
Duty/Series	Standard

General Specifications

UPC	662461289037
Weight	143.60 LB
Packaged Length	18.75 IN
Packaged Width	7.50 IN
Packaged Height	11.00 IN
HTC	8483.20.8080
Country of Origin	United States of America
