• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy 2-bolt split cast iron housing

Dimensions

Overall Length (in)	10.375 in
Base Width (in)	2.75 in
Bolt Center-to-Center Length (in)	7.815 in
Bolt Size (in)	0.625 in
Overall Width (in)	3.31 in
Overall Height (in)	5.625 in
Bore Size (in)	2.4375 in
Bolt Center Max (in)	8.688 in
Bolt Center Min (in)	6.938 in
Inner Race Length (in)	3.313 in
Centerline to Front Face (in)	2 in
Foot Height (in)	1.813 in
Base to Center Height (in)	2.75 in
Collar Outer Diameter (in)	3.938 in

Technical Specifications

Seal Type	Single Lip Contact Seal
Expansion	No
Measure Units	Inch
Rolling Element	Tapered Roller
Housing Type	Pillow Block, Two Bolt
Insert Material	52100 Bearing Steel
Housing Material	Cast Iron
Housing Base	Solid
Housing Construction	Split Two Piece
Speed (Max)	2000
Internal Clearance	Standard
Radial Dynamic Load Capacity (lb)	9,030 lb
Bore Shape	Straight
Misalignment	±3.0° Misalignment - Static Only
Locking Type	Collar Mount
End Cap	No
Misalignment Type	Static Only
Retainer Material	Steel
Bearing Insert Coating	Uncoated
Housing Color	Gray
Platform	RPB Series
Replaceable Insert	Yes
Outer Ring Land Profile	Standard
Series	RPBA
Grease Fitting Thread Size	1/8 NPT
Lubrication Type	Lithium; EP; NLGI#2
Maximum Operating Temperature (F)	220 °F
Housing Style	Pillow Block
Insert Number	RCIA-207C
Duty/Series	Standard
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Case Carburized Inner Ring

General Specifications

UPC	662288488576
Weight	20.70 LB
Packaged Length	10.50 IN
Packaged Width	5.88 IN
Packaged Height	4.13 IN
HTC	8483.20.8080
Country of Origin	United States of America
